Compact reverse jet tubular cartridge dust collector
Robust fully welded steel, hot dip galvanized construction. Weatherproof for exposed locations.
High strength, independently tested to resist explosions, for ATEX compatibility.
Tough integral mounting flange.
Low height, minimal visual impact.
Safe maintenance from clean air side.
Specifically suited for use on silos that are pneumatically filled
The SiloSafe compact reverse jet tubular cartridge dust collector, available as a venting filter or with an integral fan, was developed specifically for silo and bin venting applications – incorporating Nederman UniClean (patented) cartridge technology for maximum cleaning efficiency and extended life.
Air Volume Range: 2.600 m3/hr (1,500 CFM)
Key features
•Robust fully welded steel, hot dip galvanized construction
•Weatherproof for exposed locations
•High strength, independently tested to resist explosions, for ATEX compatibility
•Tough integral mounting flange
•Generous internal volume with 24m2 filter area
•Low height, minimal visual impact
•Safe maintenance from clean air side
Typical applications
•Venting of pneumatically filled silos and bins
•Cement batching and distribution facilities
•Venting continuously filled silos and day bins
SiloSafe 24
SiloSafe 24F
| Application | Grit;Dust;Granulate |
| Capacity (max airflow m3/h) | 2600 |
| Certifications | CE;EX |
| Filter Area (m²) | 24 |
| Filter cleaning method | Compressed air |
| Installation | Indoor;Outdoor |
| Material | 4mm fully-welded steel |
| Suitable for combustible dust | true |
| Working pressure (kPa) | -8 / +2 |
