Dust extractor arm suitable for industries where hygiene is a top priority
-
Little maintenance
-
Easy to clean
-
Double earthed
-
Flexible arm, easy to position
-
recommended for use in explosive environments, zone 22
Extraction Arm NEX D
Description
The Nederman combustible dust extraction arm NEX D is equipped with an earthed ventilation hose made of FDA approved ingredients. The NEX D dust extractor is suitable for industries where hygiene is a top priority.
The NEX D dust extraction arm has concealed joints and a separate easy to mount hose. Enclosed support arm, separate hose and a stainless steel hood means the NEX arm requires little maintenance and is easy to clean.
The NEX D arm is not marked with the EX symbol since it does not fall under the scope of the directive 2014/34/EU. Even if it does not have the EX marking, it is highly suitable for use in zones 22 according to ATEX-work directive 1999/92/EC. To be used in environments with explosive dust the arm is single earthed by the helix in the hose. The hose is made of PVC with FDA approved components.
Models
Extraction arm NEX D l=2m
Extraction arm NEX D l=3m
Extraction arm NEX D l=4m
Extraction arm NEX D l=5m
Extraction arm NEX D l=2m with damper
Extraction arm NEX D l=3m with damper
Extractor arm nex d 4m with damper
Extractor arm nex d 5m with damper
Technical Data
| Airflow (m³/h) | 1700 |
| Certifications | CE |
| Extraction arm diameter (mm) | 160 |
| Fume temperature | Max 70°C (158 F) |
| Installation | Indoor |
| Noise level (dB(A)) | 54-81 |
| Suitable for combustible dust | false |
